| Standard | TCP/IP |
| Sensor | CMOS 1/2.7" Progressive Scan |
| Screen size | 5 Mpx |
| Resolution | 2592 x 1944 (5 Mpx) |
| 2688 x 1520 (4 Mpx) |
| 2304 x 1296 (3 Mpx) |
| 1920 x 1080 (1080p) |
| 1280 x 960 (1.3 Mpx) |
| 1280 x 720 (720p) |
| Objective | 2.8mm |
| Viewing angle | 97° (manufacturer's data) |
| 93° (test carried out) |
| IR illumination range | 30 m |
| RS-485 interface | |
| Memory card slot | Support Micro SD cards up to 256GB (local recording possible) |
| Image compression method | H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| Alarm inputs/outputs | |
| Audio | Built-in microphone, network audio transmission, audio detection |
| Main stream transmission speed | 20 fps @ 5 Mpx |
| 25 fps @ 4 Mpx |
| Network interface | 10/100 Base-T (RJ-45) |
| Network protocols | IPv4/IPv6, HTTP, HTTPS, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP |
| WEB server | Incorporated |
| Maximum number of online users | 20 |
| ONVIF | 21.12 |
| Mobile access | Port: 37777 or access via cloud |
| Free DMSS application for Android |
| Free DMSS application for iOS (iPhone) |
| Default IP address | 192.168.1.108 |
| Default username / default password | admin / - |
| The administrator password must be set upon first startup |
| Browser access ports | 80, 37777 |
| Access ports via PC | 37777 |
| Mobile access doors | 37777 |
| ONVIF port | 80 |
| RTSP URL | rtsp://admin:[email protected]:554/cam/realmonitor?channel=1&subtype=0 - Main stream |
| rtsp://admin:[email protected]:554/cam/realmonitor?channel=1&subtype=1 - Subflow |
| Selected features | WDR - 120 dB, 3D-DNR, ROI, SSA, BLC, HLC, ICR, day/night mode, WB, AGC, Mirror, motion detection, privacy zones, SMD PLUS, IVS analysis: line crossing (wire trap) shot), intrusion (classification of people and vehicles), change of scenery |
| Diet | PoE (802.3af), 12V DC / 510mA |
| Energy consumption | Maximum: 7.2W @ PoE |
| Maximum: 6.1W @ 12V DC |
| Custody | Dome - Metal |
| Color | White |
| Degree of protection | IP67 |
| Anti-vandal | IK10 |
| Operating temperature | -40 °C ... 60 °C |
| Weight | 0.36kg |
| Dimensions | Ø 110 x 81 mm |
| Supported languages | Polish, English, Czech, French, Spanish, Dutch, German, Portuguese, Russian, Romanian, Turkish, Ukrainian, Hungarian, Vietnamese, Italian |
| Manufacturer / Brand | DAHUA |
| Warranty | 3 years |
