Camera
|
|
Image Sensor
|
1/2.9" CMOS
|
|
Max. Resolution
|
2688 (H) × 1520 (V)
|
|
ROM
|
128 MB
|
|
RAM
|
128 MB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual 1/3 s–1/100,000 s
|
|
Min. Illumination
|
[email protected](Color,30IRE)0.0006 [email protected](B/W,30IRE)0 lux (Illuminator on)
|
|
Y/N Ratio
|
>56dB
|
|
Illumination Distance
|
30m (98.43ft) (IR LED)
|
|
Illuminator On/Off Control
|
Car; manual
|
|
Illuminator Number
|
1 (IR LED)
|
|
Pan/Tilt/Rotation Range
|
Pan: 0°–360°Tilt: 0°–90°Rotation: 0°–360°
|
|
Lens
|
|
Lens Type
|
Fixed focal
|
|
Lens Mount
|
M12
|
|
Focal Length
|
2.8mm
|
|
Max. Openings
|
F1.6
|
|
Field of View
|
2.8mm: H: 95°; V: 52°; D: 114°;
|
|
Iris Control
|
Fixed
|
|
Close Focus Distance
|
2.8mm: 0.9m (2.95ft);
|
|
Intelligence
|
|
IVS (Perimeter Protection)
|
Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
|
|
SmartSearch
|
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
|
|
Video
|
|
Video Compression
|
H.264H; H.265; H.264; H.264B; MJPEG (Only supported by the sub stream)
|
|
Smart Codec
|
Smart H.265+; Smart H.264+
|
|
Video Frame Rate
|
Main stream: 2688 × 1520@ (1–20 fps)/2560 × 1440@(1–25/30 fps)Sub stream: 704 × 576@ (1–25 fps)/704 × 480@ (1–30 fps) Third stream: CIF@1fp*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
|
|
Stream Capability
|
3 streams
|
|
Resolution
|
4M (2688 × 1520); 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280×960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
|
|
Bitrate Control
|
CBR/VBR
|
|
Video Bitrate
|
H.264: 32kbps–6144kbpsH.265: 12kbps–6144kbps
|
|
Day/Night
|
Auto (ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
HLC
|
Yes
|
|
WDR
|
120dB
|
|
White Balance
|
Car; natural; street lamp; outdoor; manual; regional custom
|
|
Gain Control
|
Car; manual
|
|
Noise Reduction
|
3D NR
|
|
Motion Detection
|
OFF/ON (4 areas, rectangular)
|
|
Region of Interest (RoI)
|
Yes (4 areas)
|
|
Image Rotation
|
0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
|
|
Mirror
|
Yes
|
|
Privacy Masking
|
4 areas
|
|
Audio
|
|
Built-in MIC
|
Yes
|
|
Audio Compression
|
G.711a; G.711Mu; PCM; G.726
|
|
Alarm
|
|
Alarm Event
|
No SD card; SD card full; SD card error; networkdisconnecton; IP conflict; illegal access; motorbikedetector; video tampering; tripwire; intrusion; SMD; voltage detector; security except
|
|
Network
|
|
Network Port
|
RJ-45 (10/100Base-T)
|
|
SDK and API
|
Yes
|
|
Network Protocol
|
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP
|
|
Interoperability
|
ONVIF (Profile S/Profile T); CGI; P2P; Milestones
|
|
User/Host
|
6 (Total bandwidth: 36M)
|
|
Storage
|
FTP; SFTP; Micro SD card (support max. 256 GB)
|
|
Browser
|
IEChromeFirefox
|
|
Management Software
|
DSS; DMSS
|
|
Mobile Client
|
iOS; Android
|
|
Cyber Security
|
Configuration encryption;Trusted execution;Digest;Security logs;WSSE;Account lockout;syslog;Video encryption;802.1x;IP/MAC filtering;HTTPS;Trusted upgrade;Trusted boot;Generation and importing of X.509 certification
|
|
Certification
|
|
Certifications
|
CE-LVD: EN62368-1;CE-EMC: Electromagnetic Compatibility Directive2014/30/EU;FCC: 47 CFR FCC Part 15, Subpart B;UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14
|
|
Power
|
|
Power Supply
|
12VDC/PoE (802.3af)
|
|
Power Consumption
|
Basic: 2.5W (12VDC); 3.3W (PoE);Max. (ICR + H.265 + max. resolution + main stream + IR intensity + WDR + IVS): 4.2 W (12 VDC); 5.1W (PoE)
|
|
Environment
|
|
Operating Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Operating Humidity
|
≤95%
|
|
Storage Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Protection
|
IP67
|
|
Structure
|
|
Casing Material
|
Metal
|
|
Product Dimensions
|
166.2 mm × 70 mm × 70 mm (6.54" × 2.76" × 2.76") (L × W × H)
|
|
Net Weight
|
0.48 kg (1.06 lb)
|
|
Gross Weight
|
0.59 kg (1.30 lb)
|
