| System |
| Main processor | Industrial-grade processor |
| Operating system | Embedded Linux |
| Operational interface | Spiderweb; Local GUI |
| SMD Plus |
| SMD Plus Recorder | 8 channels: secondary filtering for people and vehicles, reducing false alarms caused by leaves, rain and changes in lighting conditions |
| Audio and video |
| Analog camera input | 8 BNC ports, supports HDCVI/AHD/TVI/CVBS auto detection |
| Camera input | 1. CVI: 1080p@25/30fps; 720p@25/30fps. 2.TVI: 1080p@25/30fps; 720p@25/30fps. 3. AHD: 1080p@25/30fps; 720p@25/30fps. |
| IP camera input | Up to 10 IPC access channels 2 IP channels by default + 8 channels (analog channels are converted to IP channels) Input bandwidth: 32Mbps, Recording bandwidth: 32Mbps and Output bandwidth: 32Mbps *Once IP extension is enabled, the AI (SMD) function will be disabled. |
| Coding ability | Main stream: the first channel 1080N/720p@(1 fps–25/30 fps), the others 1080N/720p@(1 fps–15 fps); 960H/D1/CIF@(1 fps–25/30 fps) Sub stream: CIF@(1 fps–7 fps) |
| Double flow | YES |
| Video bitrate | 32kbps–4096kbps |
| Audio sampling | 8kHz, 16bit |
| Audio bitrate | 64kbps |
| Video output | 1 HDMI, 1 VGA HDMI: 1920×1080, 1280×1024, 1280×720 VGA: 1920×1080, 1280×1024, 1280×720 |
| Multi-screen display | When IP extension mode is not enabled: 1/4/8/9 When IP extension mode is enabled: 1/4/8/9/16 |
| Third-party camera access | Panasonic; Sony; Hanwha; Axis; Arecont; ONVIF |
| Compression standard |
| Video compression | AI coding; Smart H.265+; H.265; Smart H.264+; H.264 |
| Audio compression | G.711a; G.711u; PCM |
| Net |
| Network protocol | HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP filter; FTP; DDNS; SNMP; Alarm server; P2P; Automatic registration; IP Search (support IP camera, DVR, NVS, etc.) |
| Access to mobile phone | iOS; Android |
| Interoperability | ONVIF 22.12 (Profile T; Profile S; Profile G); CGI; SDK |
| Navigator | Chrome; MEANING WHAT; Safari; Edge; Firefox |
| Playback of the recording |
| Recording Mode | General; alarm; motion detection |
| Playback of the recording | 1/4/9 |
| Backup method | USB device and network |
| Playback mode | Instant playback; general reproduction; event playback; tag playback; intelligent playback |
| Alarm |
| General alarm | Motion detection; HDCVI alarm; external camera alarm; network alarm; PIR alarm |
| Anomaly alarm | Error (no disk, disk error, insufficient space, insufficient quota space; network disconnect; IP conflict; MAC conflict); video loss; video tampering; offline camera |
| Smart alarm | SMD Plus |
| Connection of alarms | Documentation; snapshot (overview); External IPC alarm output; Audio; buzzer; tree trunk; preset; e-mail |
| Ports |
| Audio input | 1 channel RCA 8-channel BNC (coaxial audio) |
| Audio output | 1 channel RCA |
| Two-way conversation | Yes (share the same audio input with the first channel) |
| Disk interface | 1 SATA port, up to 16TB. This limit varies depending on the ambient temperature. |
| USB | 2 (2 rear USB 2.0 ports) |
| HDMI | 1 |
| VGA | 1 |
| Network port | 1 (10/100Mbps Ethernet port, RJ-45) |
| General |
| Power supply | 12V DC, 1.5A |
| Energy consumption | <7W (without hard drive) |
| Net weight | 0.50kg (1.10lb) |
| Gross weight | 1.07 kg (2.36 lb) |
| Product dimensions | 204.6 mm × 210.9 mm × 45.6 mm (8.06" × 8.30" × 1.80") (W × D × H) |
| Packaging dimensions | 330.0 mm × 101.0 mm × 256.0 mm (12.99" × 3.98" × 10.08") (W × D × H) |
| operating temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
| Storage temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
| Operating humidity | 10%–90% (RH), non-condensing |
| Installation | Desktops |
| Certifications | CE-LVD: IEC 62368-1:2014 CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+ A1:2015, EN 50130-4:2011+A1:2014 FCC: 47 CFR Part 15, Subpart B |
