System
|
|
Main Processor
|
Embedded processors
|
|
Operating System
|
Embedded linux
|
|
Performance
|
1 channel, 10 IVS for each channel
|
|
Object classification
|
Human/Vehicle secondary recognition for tripwire and intrusion
|
|
AI Search
|
Search by target classification (Human, Vehicle)
|
|
Record Interval.
|
1 min–60 min (default: 60 min), Pre-record: 1 s–30 s, Post-record: 10 s–300 s
|
|
Audio Compression
|
G.711A; G.711U; PCM
|
|
Audio Sample Rate
|
8 KHz, 16 bits per channel
|
|
Audio Bit Rate
|
64 kbps per channel
|
|
Display
|
|
Interface
|
1 HDMI; 1 VGA
|
|
Resolution
|
HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
|
|
Multi-screen Display
|
When IP extension mode not enabled: 1/4 When IP extension mode enabled: 1/4/8/9
|
|
OSD
|
Camera title; Time; Video loss; Camera lock; Motion detection; Recording
|
|
Network
|
|
Interface
|
1 RJ-45 Port (100MB)
|
|
Network Function
|
HTTP; HTTPS; TCP/IP; IPv4/IPv6; Wifi; 3G/4G; SNMP; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; P2P; IP Search (Supports Dahua IP camera, DVR, NVS, etc.)
|
|
Max. User Access
|
128 users
|
|
Smart Phones
|
iPhone; iPad; Android
|
|
Interoperability
|
ONVIF® 16.12, CGI Conformant
|
|
Video Detection and Alarm
|
|
Trigger Events
|
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
|
|
Video Detection
|
Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis
|
|
Alarm input
|
N/A
|
|
Relay Output
|
N/A
|
|
Playback and Backup
|
|
Playback
|
1/4
|
|
Search Mode
|
Time/Date, Alarm, MD and Exact Search (accurate to second)
|
|
Playback Function
|
Play; Breaks; Stop; Rewind; Fast play; Slow Play; NextFile; Previous File; Next Camera; Previous Camera; Full Screen; Repeat; Shuffles; Backup Selection; Digital Zoom
|
|
Backup Mode
|
USB Device/Network
|
|
Ports
|
|
Audio Input
|
1-channel RCA4-channel BNC (Coaxial Audio)
|
|
Audio Output
|
1-channel RCA
|
|
Two-way Talk
|
Yes (share the same audio input with the first channel)
|
|
HDD Interface
|
1 SATA port, up to 16 TB. The maximum HDD capacity varies with environment temperature.
|
|
USB
|
2 USB ports (USB 2.0)
|
|
RS485
|
N/A
|
|
RS232
|
N/A
|
|
Electrical
|
|
Power Supply
|
DC 12V/2A
|
|
Power Consumption
|
< 7W
|
|
Construction
|
|
|
Dimensions
|
Smart 1U, 204.6 mm × 210.9 mm × 45.6 mm (8.06'' × 8.30'' × 1.80'')
|
|
Net Weight(without HDD)
|
0.53 kg (1.17 lb)
|
|
Gross Weight
|
1.07 kg (2.36 lb)
|
|
Installation
|
Desktop installation
|
|
Environmental
|
|
|
Operating Conditions
|
-10°C to +55°C (+14°F to +131°F), 0%–90% (RH)
|
|
Storage Conditions
|
-20°C to +70°C (-4°F to +158°F), 0%–90% (RH)
|
|
Third-party Support
|
|
|
Third-party Support
|
Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more
|
|
Certifications
|
|
|
Certifications
|
FCC: Part 15 Subpart B
|
|
CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2; EN 61000-3-3; EN 55032; EN 50130; EN 55024
|
