| SYSTEM |
| Main Processor | Embedded Processor |
| Operating System | Embedded LINUX |
| Operating Interface | Web; Local GUI |
| Perimeter protection |
| Perimeter Performance AI by Recorder (Number of Channels) | Advanced Model: 1 channel, 10 IVS for each channel General Model: 4 channels, 10 IVS for each channel |
| Face detection |
| Face Attributes | Gender; age group; glasses; expressions; face mask; beard |
| Face Detection Performance of AI by Recorder (Number of Channels) | 1 channel (up to 8 face images/s) |
| Face Recognition |
| Face Database Capacity | Up to 10 face databases and 20,000 images. |
| Face Recognition Performance of AI by Recorder (Number of Channels) | 1 channel |
| SMD Plus |
| SMD Plus by Recorder | 4-channel: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change |
| Audio and Video | |
| Analog Camera Input | 4 channels, BNC: adaptive access by default; HDCVI, AHD, TVI and CVBS access can be configured. |
| Input Chamber | 1. CVI: 4K, 6MP, 5MP, 4MP, 1080p@25/30fps, 720p@50/60fps, 720p@25/30fps. 2. TVI: 4K, 5MP, 4MP, 3MP, 1080p@25/30fps, 720p@25/30fps. 3. AHD: 4K, 5MP, 4MP, 3MP, 1080p@25/30fps, 720p@25/30fps. |
| IP Camera Input | Up to 8 channels of IPC access 4 IP channels by default + 4 channels (analog channels are converted to IP channels) incoming bandwidth: 64 Mbps, recording bandwidth: 64 Mbps and outgoing bandwidth: 64 Mbps *After IP channels are added beyond the existing channels, the AI Function (IVS, SMD, FACE) will be disabled. |
| Encoding Capacity | Main stream: All channel 4K (1 fps–7 fps); 6MP (1fps– 10 fps); 5MP (1fps–12fps); 4K-N, 4MP/3MP (1fps–15fps); 4M-N/1080p/720p/960H/D1/CIF (1fps–25/30fps); Sub steram: 960H (1 fps–15 fps); D1/CIF (1 fps–25/30 fps) |
| Dual-stream | Yes |
| Video Bit Rate | 32kbps–6144kbps |
| Audio Sampling | 8kHz, 16bit |
| Audio Bit Rate | 64kbps |
| Video Output | 1 HDMI, 1 VGA VGA: 1920×1080, 1280×1024, 1280×720 HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 |
| Multi-screen Display | When IP extension mode not enabled: 1/4 When IP extension mode enabled: 1/4/8/9 |
| Third-party Camera Access | ONVIF®; RTSP; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Samsung |
| Standard compression |
| Video Compression | AI Coding; H.265+; H.265; H.264+; H.264 |
| Audio Compression | G.711a; G.711u; PCM |
| Network |
| Network Protocol | HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; P2P |
| Mobile Phone Access | iOS; Android |
| Interoperability | ONVIF® 21.06; CGI Conformant |
| Browsers | Chrome IE9 or later Firefox |
| Network Mode | Single-address mode |
| Recording Playback |
| Record Mode | General, motion detection; intelligent; alarm; POS |
| Recording Playback | 1/4 |
| Backup Method | USB device and network |
| Playback Mode | Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection) |
| Alarm |
| General Alarm | Motion detection, video loss, tampering |
| Anomaly Alarm | No disk, disk error, low space, offline, ip conflict, MAC conflict |
| Intelligent Alarm | Face detection, face recognition, perimeter protection |
| Alarm Linkage | Record, snapshot (panoramic), IPC external alarm output, access controller, voice prompt, buzzer, log, preset, email |
| Ports |
| Audio Input | 1-channel RCA 4-channel BNC (Coaxial Audio) |
| Audio Output | 1-channel RCA |
| Two-way Talk | Yes (share the same audio input with the first channel) |
| HDD Interface | 1 SATA port, up to 16 TB. The maximum HDD capacity varies with environment temperature. |
| RS-485 | 1 port, for PTZ control |
| USB | 2 USB ports (USB 2.0) |
| HDMI | 1 |
| VGA | 1 |
| Network port | 1 (10/100 Mbps Ethernet port, RJ-45) |
| General |
| Power Supply | 12 VDC, 2 A |
| Power Consumption | <7W |
| Net Weight | 0.53 kg (1.17 lb) |
| Gross Weight | 1.07 kg (2.36 lb) |
| Product Dimensions | 260.0 mm × 237.9 mm × 47.6 mm (10.24'' × 9.37'' × 1.87'') (W × D × H) |
| Packaging Dimensions | 333.0 mm × 315.0 mm × 89.0 mm (13.11" × 12.40" × 3.50") (W× D × H) |
| Operating Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
| Operating Humidity | 0%–90% (RH) |
| Installation | Desktops |
| Certifications | FCC: Part 15 Subpart B CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2; EN 61000-3-3; EN 55032; EN50130; EN 55024 |
