| System |
| Main processor | Industrial-grade processor |
| Operating system | Embedded Linux |
| Operational interface | Spiderweb; Local GUI |
| Perimeter protection |
| AI perimeter performance per recorder (number of channels) | Advanced Model: 2 channels, 10 IVS for each channel General model: 4 channels, 10 IVS for each channel |
| Facial recognition |
| Facial attributes | Type; age range; eyeglasses; expressions; mask; beard |
| AI face detection performance per recorder (number of channels) | 2 channels (up to 8 face images per channel) |
| Facial recognition |
| Face database capacity | Up to 10 face databases with 10,000 face images in total. You can add name, gender, date of birth, address, certificate type, certificate number, countries, regions and status to each face image |
| AI facial recognition performance per recorder (number of channels) | 2 channels |
| SMD Plus |
| SMD Plus Recorder | 8 channels: secondary filtering for people and motor vehicles, reducing false alarms caused by leaves, rain and changes in lighting conditions |
| Audio and Video |
| Analog camera input | 8 BNC ports, supports HDCVI/AHD/TVI/CVBS auto detection |
| Camera input | 1. CVI: 5MP@20fps, 5MP@25fps, 5MP@10/12.5fps, 4MP@25/30fps, 1080p@25/30fps, 720p@50/60fps, 720p@25/30fps. 2. TVI: 5MP@20fps, 4MP@25/30fps, 1080p@25/30fps, 720p@25/30fps. 3. AHD: 5MP@20fps, 4MP@25/30fps, 1080p@25/30fps, 720p@25/30fps |
| IP camera input | Up to 12 IPC access channels 4 IP channels by default + 8 channels (analog channels are converted to IP channels) incoming bandwidth: 64 Mbps, recording bandwidth: 64 Mbps and outgoing bandwidth: 64 Mbps *After adding IP channels in addition to the existing ones, the AI function (IVS, SMD, FACE) will be disabled |
| Coding ability | Mainstream: 5MP mode: 4 channels 5MP@(1-6fps); other channels 5M-N@(1-12fps) 5M-N mode: All channels 5M-N@(1–12fps);4M-N,1080p@(1–15fps); 1080N, 720p, 960H, D1,CIF@(1–25/30fps) Sub stream: D1, CIF@(1–15fps) |
| Double flow | YES |
| Video bitrate | 32kbps–6144kbps |
| Audio sampling | 8kHz, 16bit |
| Audio bitrate | 64kbps |
| Video output | 1 HDMI, 1 VGA VGA: 1920×1080, 1280×1024, 1280×720 HDMI: 1920×1080, 1280×1024, 1280×720 |
| Multi-screen display | When IP extension mode is not enabled: 1/4/8/9 When IP extension mode is enabled: 1/4/8/9/16 |
| Third-party camera access | ONVIF; Panasonic; Sony; Axis; Arecont; SAMSUNG |
| Compression standard |
| Video compression | AI coding; Smart H.265+; H.265; Smart H.264+; H.264 |
| Audio compression | G.711a; G.711u; PCM |
| Net |
| Network protocol | HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP filter; DDNS; Alarm server; P2P; Automatic registration |
| Access to mobile phone | iOS; Android |
| Interoperability | ONVIF 22.12(Profile T; Profile S; Profile G); CGI; SDK |
| Navigator | Chrome IE9 or later Firefox |
| Network mode | Single address mode |
| Playback of the recording |
| Recording Mode | General, motion detection; intelligent; alarm; POS |
| Playback of the recording | 1/4/9 Changes to 1/4 subdivision when Face or IVS&SMD is selected in AI mode. |
| Backup method | USB device and network |
| Playback mode | Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection) |
| Alarm |
| General alarm | Motion detection; video loss; video tampering |
| Anomaly alarm | No disk; disk error; disk full; disconnected; IP conflict; MAC conflict |
| Smart alarm | Facial recognition; Facial recognition; perimeter protection |
| Connection of alarms | Documentation; snapshot (overview); External IPC alarm output; voice command; buzzer; tree trunk; preset; e-mail |
| Ports |
| Audio input | 1 channel RCA 8-channel BNC (coaxial audio) |
| Audio output | 1 channel RCA |
| Two-way conversation | Yes (share the same audio input with the first channel) |
| HDD interface | 1 SATA port, capacity up to 16TB. The maximum HDD capacity varies depending on the ambient temperature |
| RS-485 | 1 port, for PTZ control |
| USB | 2 (1 front USB 2.0 port, 1 rear USB 2.0 port) |
| HDMI | 1 |
| VGA | 1 |
| Network port | 1 (10/100Mbps Ethernet port, RJ-45) |
| VGA | 1 |
| Network port | 1 (10/100Mbps Ethernet port, RJ-45) |
| General |
| Power supply | 12V DC, 2A |
| Energy consumption | <7W (without hard drive) |
| Net weight | 1.17kg (2.58lbs) |
| Gross weight | 1.78 kg (3.93 lb) |
| Product dimensions | 325.0 mm × 257.1 mm × 55.0 mm (12.80'' × 10.12'' × 2.17'') (W × W × H) |
| Packing dimensions | 372.0 mm × 117.0 mm × 308.0 mm (14.65'' × 4.61'' × 12.13'') (W × D × H) |
| operating temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
| Storage temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
| Operating humidity | ≤93% (RH) |
| Installation | Rack or desktop |
| Certifications | CE: CE-LVD: IEC 62368-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024, EN 55035 |
