| System |
| Main processor | Industrial grade processor |
| Operating system | Embedded Linux |
| Operational interface | Web; Local GUI |
| Quick Pick 2.0 |
| QuickPick 2.0 AI Recorder (Number of Channels) | 2 channels |
| Perimeter protection |
| Perimeter Performance AI per recorder (number of channels) | Advanced mode: 2 channels, 10 IVS rules for each channel General mode: 4 channels, 10 IVS rules for each channel |
| Face detection |
| Facial Attributes | 6 attributes |
| AI face detection performance via recorder (number of channels) | 2 channels (up to 12 face images/s per channel) |
| Facial recognition |
| Face database capacity | Up to 10 face databases with 10,000 images. |
| AI facial recognition performance via recorder (number of channels) | 2 channels |
| SMD Plus |
| SMD Plus by Recorder | 16 channels: Secondary filtering for people and motor vehicles, reducing false alarms caused by leaves, rain and changes in lighting conditions |
| SMD Plus Camera | 24 channels |
| AI Video Quality Analysis |
| AI Video Quality Analysis via Recorder | 16 channels: Supports detection of brightness levels, color cast, blur, overexposure, contrast levels, black and white |
| Scene change |
| Scene change via recorder | 1 channel |
| Irregular black block masking |
| Irregular black block masking by recorder | 1 channel |
| Audio and Video |
| Analog camera input | 16 BNC ports, support HDCVI/AHD/TVI/CVBS auto detection |
| Camera input | Resolution: 1. CVI: 5MP at 25fps; 5 MP at 20 fps; 5 MP at 10/12.5 fps; 4 MP at 25/30 fps; 1080p at 25/30 fps; 720p at 50/60 fps; 720p at 25/30 fps. 2. TVI: 5 MP (2560 x 1944) at 20 fps; 5 MP (2960 x 1665) at 20 fps; 4 MP at 25/30 fps; 1080p at 25/30 fps; 720p at 25/30 fps. 3. AHD: 5MP at 20fps; 4 MP at 25/30 fps; 1080p at 25/30 fps; 720p at 25/30 fps. |
| IP camera input | Up to 24 IPC access channels 8 default IP channels + 16 channels (analog channels are converted to IP channels) Incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps *After enabling IP Extension, you will no longer be able to use Video Quality Analytics, Scene Changing, Face Recognition, Face Detection, SMD, Perimeter Protection and QuickPick 2.0 features. |
| Coding skills | Mainstream: 5MP Mode: 4 channels 5MP@(1fps-6fps); other 5M-N@(1fps-12fps) 5M-N mode: 5M-N@(1 fps –12 fps); 4M-N/1080p@(1fps–15fps); 1080N/720p/960H/D1/CIF@(1fps–25/30fps) Substream: D1/CIF@(1 fps–15 fps) |
| Double flow | YES |
| Video Bitrate | 32kbps–6144kbps |
| Audio Sampling | 8kHz, 16bit |
| Audio bit rate | 64kbps |
| Video output | 1 HDMI, 1 VGA Resolution: 1920×1080, 1280×1024, 1280×720 Maximum resolution: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 Changes to 1920×1080, 1280×1024, 1280×720 when selecting Face, IVS&SMD or Shortcut in AI Mode. |
| Multi-screen display | When IP extension mode is not enabled: 1/4/8/9/16 When IP extension mode is enabled: 1/4/8/9/16/25 |
| Third-party camera access | Panasonic; Sony; Hanwha; Axis; Arecont; ONVIF |
| Compression standards |
| Video Compression | AI coding; Smart H.265+; H.265; Smart H.264+; H.264 |
| Audio compression | G.711a; G.711u; PCM |
| Net |
| Network Protocol | HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Record; IP Search (Support IP Camera, DVR, NVS, etc.) |
| Mobile phone access | iOS; Android |
| Interoperability | ONVIF 24.06 (Profile T; Profile S; Profile G); CGI; SDK |
| Navigator | Chrome; Internet Explorer; Safari; Edge; Firefox |
| Record Playback |
| Registration mode | General; Alarm; Motion Detection; Smart; POS |
| Record Playback | 1/4/9/16 Switch to 1/4/9 split when selecting Face or IVS&SMD in AI mode. |
| Backup method | USB Device and Network |
| Playback Mode | Instant playback; General playback; Event playback; Tag playback; Smart playback |
| Alarm |
| General alarm | Motion detection; HDCVI alarm; External camera alarm; Network alarm; PIR alarm |
| Anomaly alarm | Error (no disk, disk error, insufficient space, insufficient quota space; network disconnection; IP conflict; MAC conflict); video loss; video tampering; camera offline |
| Smart Alarm | Face detection; Face recognition; Perimeter protection; SMD Plus |
| Alarm connection | Recording; snapshot (overview); IPC external alarm output; audio; buzzer; log; preset; email |
| Ports |
| Audio input | 1 channel RCA 16-channel BNC (coaxial audio) |
| Audio output | 1 channel RCA |
| Two-way conversation | Yes (share the same audio input with the first channel) |
| Disk Interface | 1 SATA port, up to 16TB. This limit varies depending on ambient temperature. |
| RS-485 type | 1 |
| USB | 2 (1 front USB 2.0 port, 1 rear USB 3.0 port) |
| HDMI cable | 1 |
| VGA | 1 |
| Network port | 1 (10/100/1000 Mbps Ethernet port, RJ-45) |
| General |
| Power supply | 12VDC, 2A |
| Energy consumption | <12W (without HDD) |
| Net weight | 1.15 kg (2.54 lbs) |
| Gross weight | 1.95 kg (4.30 lbs) |
| Product dimensions | 325.0 mm × 257.1 mm × 55.0 mm (12.80" × 10.12" × 2.17") (W × D × H) |
| Packaging dimensions | 372.0 mm × 117.0 mm × 308.0 mm (14.65" × 4.61" × 12.13") (W × D × H) |
| Operating temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
| Storage temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
| Operating humidity | 10%–90% (RH), non-condensing |
