| System |
| Main processor | Built-in processor |
| Operating system | Embedded Linux |
| Operational interface | Spiderweb; Local GUI |
| Perimeter protection |
| AI perimeter performance per recorder (number of channels) | Advanced Model: 2 channels, 10 IVS for each channel General model: 4 channels, 10 IVS for each channel |
| Facial recognition |
| Facial attributes | Type; age range; eyeglasses; expressions; mask; beard |
| AI face detection performance per recorder (number of channels) | 2 channels (up to 12 face images) |
| Facial recognition |
| Face database capacity | Up to 10 face databases with 10,000 face images in total. You can add name, gender, birthday, address, certificate type, certificate number, countries and state to each face image |
| AI facial recognition performance per recorder (number of channels) | 2 channels |
| SMD Plus |
| SMD Plus Recorder | 16 Channels: Secondary filtering for people and motor vehicles SMD Plus, reducing false alarms caused by leaves, rain and changes in lighting conditions |
| Audio and video |
| Analog camera input | 16 BNC ports, CVI access by default, supports HDCVI/AHD/TVI/CVBS auto detection |
| Camera input | CVI: 5MP@20fps, 5MP@25fps, 5MP@10/12.5fps, 4MP@25/30fps, 1080p@25/30fps, 720p@50/60fps, 720p@25/30fps. TVI: 5MP@20fps, 4MP@25/30fps, 1080p@25/30fps, 720p@25/30fps. AHD: 5MP@20fps, 4MP@25/30fps, 1080p@25/30fps, 720p@25/30fps. |
| IP camera input | Up to 24 IPC access channels 8 IP channels by default + 16 channels (analog channels are converted to IP channels) incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps *After adding IP channels in addition to the existing ones, the AI function (IVS, SMD, FACE) will be disabled. |
| Coding ability | Mainstream: 5MP mode: 4 channels 5MP@(1-6fps); other channels 5M-N@(1-12fps) 5M-N mode: All channels 5M-N@(1–12fps);4M-N,1080p@(1–15fps); 1080N, 720p, 960H, D1,CIF@(1–25/30fps) Sub stream: D1, CIF@(1–15fps) |
| Double flow | YES |
| Video frame rate | PAL: 1fps–25fps. NTSC: 1fps–30fps. |
| Video bitrate | 32Kbps–6144Kbps per channel |
| Audio sampling | 8KHz, 16bit |
| Audio bitrate | 64Kbps |
| Video output | 1 HDMI, 1 VGA VGA: 1920×1080, 1280×1024, 1280×720 HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 Changes to 1920 × 1080, 1280 × 1024, 1280 × 720 when Face or IVS&SMD is selected in AI mode. |
| Multi-screen display | When IP extension mode is not enabled: 1/4/8/9/16 When IP extension mode is enabled: 1/4/8/9/16/25 |
| Third-party camera access | Onvif, Panasonic, Sony, Axis, Arecont, Pelco, Canon, Samsung |
| Compression standard |
| Video compression | AI/H.265+/H.265/H.264+/H.264 encoding |
| Audio compression | G.711A/G.711u/PCM |
| Net |
| Network protocol | HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP filter; FTP; DDNS; Alarm server; P2P; Automatic registration; IP Search (support IP camera, DVR, NVS, etc.) |
| Access to mobile phone | iPhone, iPad, Android |
| Interoperability | ONVIF 22.12(T Profile; S Profile; G Profile); CGI; SDK |
| Navigator | Chrome, IE9 or later, Firefox |
| Network mode | Single address mode |
| Playback of the recording |
| Recording Mode | General, motion detection; intelligent; alarm; POS |
| Playback of the recording | 4/1/9/16 Changes to 1/4/9 division when Face or IVS&SMD is selected in AI mode. |
| Backup method | USB/Network Device |
| Playback mode | Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection) |
| Alarm |
| General alarm | Motion detection, video loss, tampering and local alarm |
| Anomaly alarm | No disk, disk error, out of space, offline, IP conflict, MAC conflict |
| Smart alarm | Face detection, face recognition, perimeter protection |
| Connection of alarms | Recording, Snapshot (Overview), IPC External Alarm Output, Access Controller, Voice Command, Buzzer, Log, Preset, Email |
| Ports |
| Audio input | 16-channel RCA (external) 16-channel BNC (coaxial audio) |
| Audio output | 1 channel RCA |
| Two-way conversation | Yes (share the same audio input with the first channel) |
| Alarm input | 16 channels |
| Alarm output | 3 channels |
| HDD interface | 1 SATA port, up to 16TB, the maximum HDD capacity varies depending on the ambient temperature |
| RS-485 | 1 port, for PTZ control |
| USB | 2 (1 front USB 2.0 port, 1 rear USB 3.0 port) |
| HDMI | 1 |
| VGA | 1 |
| Network port | 1 (10/100/1000Mbps Ethernet port, RJ-45) |
| General |
| Power supply | 12V DC, 2A |
| Energy consumption | Less than 12W |
| Net weight | 1.36kg (3.00lbs) |
| Gross weight | 2.16 kg (4.76 lb) |
| Product dimensions | Mini 1U, 325.0mm × 257.1mm × 55.0mm 12.80'' × 10.12'' × 2.17'' (W × D × H) |
| Packing dimensions | 372.0mm × 117.0mm × 308.0mm 14.65" × 4.61" × 12.13" (W × D × H) |
| operating temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
| Operating humidity | 10%–90% |
| Installation | Desktops |
| Certifications | CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 FCC: Part 15 Subpart B |
