| Camera |
| Image sensor | 1/3" progressive scan CMOS. |
| Maximum. Resolution | 2560×1440 |
| minimum lighting | Color: 0.005 Lux @ (F1.6, AGC ON), Black & White: 0 Lux with IR |
| Shutter time | From 1/3 to 1/100,000 s |
| Day night | IR cut filter |
| Angle adjustment | Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360° |
| Lens | |
| Lens type | Varifocal lens, motorized lens, 2.8 to 12 mm |
| Focal length and field of view | 2.8 to 12 mm, horizontal FOV 95.9° to 29.2°, vertical FOV 50.6° to 16.4°, diagonal FOV 114.7° to 33.5° |
| Lens attachment | Ø14 |
| Type of iris | Fixed |
| Opening | F1.6 |
| Illuminator |
| Additional light type | IR |
| Supplement to the range of lights | Up to 50 m |
| Intelligent supplementary light | YES |
| IR wavelength | 850 nm |
| video |
| Mainstream | 50 Hz: 20 fps (2560 × 1440), 25 fps (1920 × 1080, 1280 × 720), 60 Hz: 20 fps (2560 × 1440), 24 fps (1920 × 1080, 1280 × 720) |
| Underflow | 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360), 60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360) |
| Video compression | Main stream: H.265+/H.265/H.264+/H.264, Sub stream: H.265/H.264/MJPEG |
| Video bitrate | From 32Kbps to 8Mbps |
| H.264 type | Basic profile, main profile, high profile |
| H.265 type | Main profile |
| Region of Interest (ROI) | 1 fixed region(s) for the main flow |
| Net |
| Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP |
| Simultaneous live viewing | Up to 6 channels |
| APIs | Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK |
| Safety | Password protection, strong password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address) |
| User/Guest | Up to 32 users, 3 user levels: administrator, operator and user |
| Customer | iVMS-4200, Hik-Connect |
| Web browsing program | Plugin Request Live View: IE 10, IE 11, Local Service: Chrome 57.0+, Firefox 52.0+ |
| Image |
| Image settings | Rotation, saturation, brightness, contrast, sharpness, gain, white balance modes, adjustable via client software or web browser |
| Day/night switching | Day, Night, Automatic, Programming |
| Wide Dynamic Range (WDR) | 120dB |
| Image enhancement | BLC, HLC, 3D DNR |
| Interface | |
| Ethernet interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
| Storage on board | Built-in memory card slot, supports microSD/microSDHC/microSDXC cards, up to 256GB |
| Reset key | YES |
| Event |
| Basic event | Motion detection (supports alarm triggering by specific target types (human and vehicle)), video tampering alarm, exception |
| Connection | Upload to FTP/Memory Card, Notify Surveillance Center, Send Email, Enable Recording, Enable Capture |
| General |
| Power | 12 VDC ± 25%, 0.9 A, max. 11W Coaxial Power Plug, Ø5.5mm, PoE: 802.3af, Class 3, 36V to 57V, 0.36A to 0.23A, Max. 12.9W |
| Dimension | Ø105mm × 244.4mm (Ø4.1 × 9.6") |
| Package size | 315 mm × 137 mm × 141 mm (12.4" × 5.4" × 5.6") |
| Weight | approx. 705 g (1.6 lb) |
| With package weight | approx. 1085g (2.4lbs) |
| Storage conditions | -30°C to 60°C (-22°F to 140°F). Humidity 95% or less (non-condensing) |
| Starting and operating conditions | -30°C to 60°C (-22°F to 140°F). Humidity 95% or less (non-condensing) |
| Tongue | English, Ukrainian |
| General function | Heartbeat, anti-banding, mirror, password protection, privacy mask, watermark |
| Approval |
| EMC | FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4:2011+A1:2014 |
| Safety | CE-LVD: EN 62368-1: 2014/A11: 2017 |
| Environment | CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Scope: Regulation (EC) no. 1907/2006 |
| Protection | IP67: IEC 60529-2013 |
