In stock
|
SKU: 12300
This product will be shipped within 3 working days
There are different forms of payment: 0 interest installments, bank transfer, PayPal, credit card and cash on delivery with a supplement of €6.00.













The DEYE SUN-40K-SG01HP3-EU-BM4 photovoltaic inverter combines power, efficiency, and versatility in a single three-phase hybrid system. With support for high-voltage LiFePO₄ batteries, on-grid/off-grid compatibility, and four independent MPPTs, it offers maximum flexibility for large-scale residential and commercial systems.
Battery Compatibility:
| SKU | Degree of Protection | Battery Capacity (kWh) | CEI 0-21 |
|---|---|---|---|
| 11900 | IP55 | 61.44 kWh | ✔ |
| 11862 | IP20 | 5.12 kWh | ✔ |
| 11994 | IP20 | 61.44 kWh | ✔ |
| 12296 | IP20 | 40.96 kWh | ✔ |
| 12355 | IP20 | 81.92 kWh | ✔ |
| Chimica batteria compatibile | LFP (LiFePO₄) |
| Architettura batteria compatibile | Alta Tensione (HV) |
| Range tensione batteria | 160 – 800 V |
| Corrente di carica massima | 50 A |
| Corrente di scarica massima | 50 A |
| Numero ingressi batteria | 2 |
| Curva di carica | 3 stadi / Equalizzazione |
| Strategia di ricarica | Autoadattamento al BMS (Li-ion) |
| Sensore di temperatura esterno | Sì |
| Potenza ingresso massima | 64 kW |
| Tensione di avvio | 180 V |
| Tensione nominale MPPT | 600 V |
| Range tensione MPPT | 150 – 850 V |
| Tensione minima di esercizio | 150 V |
| Tensione massima in ingresso per MPPT | 1000 V |
| Corrente massima per MPPT | 36 A |
| Corrente corto circuito MPPT | 55 A |
| Numero tracker MPPT | 4 |
| Stringhe per MPPT | 2 / 2 / 2 / 2 |
| Sistema elettrico inverter | Trifase |
| Potenza massima AC | 40 kW |
| Output inverter | 230-400 V (3L + N + PE) |
| Tensione di rete | 380 / 400 V |
| Corrente massima uscita | 63,8 A |
| Frequenza rete | 50 / 60 Hz |
| Fattore di potenza | 0,8 lag – 0,8 lead |
| THDi | < 3 % |
| Efficienza massima | 97,6 % |
| Efficienza MPPT | 99,9 % |
| Protezione contro i fulmini FV | Integrato |
| Protezione anti-isola | Integrato |
| Rilevamento resistenza isolamento | Integrato |
| Protezione inversione polarità | Integrato |
| Protezione sovracorrente uscita | Integrato |
| Protezione cortocircuito uscita | Integrato |
| Protezione sovratensione uscita | Integrato |
| Protezione sovratensioni | Integrato |
| Unità monitoraggio corrente residua | Integrato |
| Produttore Inverter | DEYE |
| Tipo installazione | A parete |
| Comunicazione | RS485 / RS232 / CAN / WiFi |
| Consumo energia notturno | < 3 W |
| Raffreddamento | Attivo (con ventole) |
| Livello rumore | < 65 dB |
| Altitudine massima di funzionamento | 2000 m |
| Umidità relativa | 0 – 95 % |
| Grado di protezione | IP65 |
| Colore | Bianco |
| Dimensioni (L×H×P) | 527 × 894 × 294 mm |
| Temperatura di esercizio | –40 ÷ +60 °C |
| Garanzia materiali | 10 anni |
| Ean | Non Applicabile |
|---|---|
| Shipping | Shipping 7 days |
| Warranty | 10 years warranty |
| Colore | White |
| Waterproof | IP65 |
| Tipo_tensione_lvhv | High Voltage |
| Power | 40 |
| Communication | RS485(standard), Wi-Fi / Bluetooth, Ethernet |
| Inverter Type | Hybrid |
| Current | Three-phase |
